29
If repairs to the system or individual components are necessary, contact your specialist dealer or our
service centre (see below for address).
• The cables laid within the vehicle can remain there
• Unscrew the six M6 screws securing the turntable to the mounting plate
• Place two wooden supports on the vehicle roof, for protection
• Then place the turntable on the prepared wooden supports
• To ship the turntable, use the original packaging which you have saved
• Seal the opening in the vehicle roof appropriately to protect against the ingress of moisture
• If a HDZ 100 roof gland has been fi tted and the equipment is then removed, the cable channels
no longer used should be sealed with the integral plugs. The enclosure is then watertight once again.
Note: Before exchanging the UFS 940sw, fi rst move the turntable to the park position.
ESC
Electronic Service Chiemgau GmbH
Bahnhofstraße 108
83224 Grassau GERMANY
Tel: +49 8641 9545-0
Fax: +49 8641 9545-35 and -36
Internet: http://www.esc-kathrein.de
E-Mail: service@esc-kathrein.de
DISMANTLING FOR SERVICING
DISMANTLING
ADDRESS OF THE SERVICE CENTRE
KATHREIN Sachsen GmbH
Lindenstraße 3
09241 Mühlau GERMANY
Tel: +49 3722 6073-31
Fax: +49 3722 6073-18
E-Mail: service@kathrein-sachsen.de
Factory repair centre Regional repair centre
Never open the turntable yourself!
Do not cut the cables! At the cable junction provided, disconnect the cables
projecting from the turntable from the two cables laid within the interior of the
vehicle (unplug the plug).
