38 English
(*) Computer used with the DEXIS Titanium sensor must meet this rating.
Guidance and manufacturer’s declaration - electromagnetic immunity
The DEXIS Titanium sensor, used with a compliant computer, is intended for use in the electromagnetic environment specified
below. The customer or the user of the DEXIS Titanium sensor should assure that it is used in such an environment.
Immunity test IEC 60601
test level
Compliance
level
Electromagnetic environment - guidance
Electrostatic
discharge
(ESD)
IEC 61000-4-2
+/-8 kV contact
+/-2kV, +/-4 kV, +/-8 kV, +/-15 kV air
Complies Floors should be wood, concrete or ceramic tile. If floors
are covered with synthetic material, the relative humid-
ity should be at least 30%.
Electrical fast
transient/burst
IEC 61000-4-4
+/-2 kV for
power supply lines
+/-1 kV for input/output lines
Complies (*) Mains power quality should be that of a typical commer-
cial or hospital environment.
Surge
IEC 61000-4-5
+/-1 kV
differential mode
+/-2 kV common mode
Complies (*) Mains power quality should be that of a typical commer-
cial or hospital environment.
Voltage dips,
short interrup-
tions and volt-
age variations
on power sup-
ply input lines
IEC 61000-4-11
0% U
T
; 0.5 cycle at 0
o
, 45
o
, 90
o
, 135
o
,
180
o
, 225
o
, 270
o
, and 315
o
0% U
T
; 1 cycle
70% U
T
; 25/30 cycles for 50 Hz and
60 Hz, respectively
Single phase: at 0
o
0% U
T
; 250/300 cycle for 50 Hz and
60 Hz respectively
Single phase: at 0
o
Complies (*) Mains power quality should be that of a typical commer-
cial or hospital environment. If the user of the sensor re-
quires continued operation during power mains
interruptions, it is recommended that the sensor be
powered from an uninterruptible power supply or a bat-
tery.
VDI specs per 3
rd
edition:
<5% U
T
(>95% dip in U
T
) for 0,5 cycle
40% U
T
(60% dip in U
T
) for 5 cycles
70% U
T
(30% dip in U
T
) for 25 cycles
<5% U
T
(>95% dip in U
T
) for 5 s
Power frequen-
cy (50/60 Hz)
magnetic field
IEC 61000-4-8
30 A/m, 50 Hz or 60 Hz Complies Power frequency magnetic fields should be at levels
characteristic of a typical location in a typical commer-
cial or hospital environment.
NOTE 1 U
T
is the a.c. mains voltage prior to application of the test level.
