KaVo EWL 2 - Technical Data

15
Electric Dispenser Hoist EWL 2, 3, 4
A 11 Technical data
Dimensions:
Length:
Dispenser hoist EWL 2 1540 mm
Dispenser hoist EWL 3 1950 mm
Dispenser hoist EWL 4 2360 mm
Depth:
Dispenser hoist EWL 2/3/4 1150 mm
Weight:
Dispenser hoist EWL 2 75 kg
Dispenser hoist EWL 3 80 kg
Dispenser hoist EWL 4 85 kg
Connected load: 200 W
Max. load capacity: 500 N
Static load:
Working load 500 N
(300 N plaster + 200 N dispenser weight)
+ 300 N
hoist weight (Silolift)
Total weight 800 N
FGD1=1000 N
Dynamic shock load during operation
FGD1=1000 N
Rated voltage
Voltage range: 100- 127 V 50/60 Hz
220- 240 V 50/60 Hz
Connected load: 200 W
Method of operation: S2 - 5 min
Decibel emissions: < 70 dB (A)
Year of manufacture: see nameplate
We reserve the right to make any alterations
Rated voltage
Voltage range: 100- 127 V 50/60 Hz
220- 240 V 50/60 Hz
Connected load: 200 W
Method of operation: S2 - 5 min
Decibel emissions: < 70 dB (A)
