4
Electric Dispenser Hoist EWL 2, 3, 4
A 4 Location
Proper operation
of the electric hoist Silolift can be achieved
only in accordance with the requirements
laid out in DIN EN 61010.
- Internal use
- Temperature range 5°C to 40°C
- max. relative humidity 80% at
temperatures up to 3°C, which linearly
reduces to 50% relative humidity at
40°C
Voltage fluctuations must not vary
more than ±10% of the nominal voltage.
- Excessive voltage in accordance with
installations- category (voltage-surge
category) II (see Appendix J).
For minimum and normal
electricity supply, Category II applies.
- Degree of pollution 2 according to
IEC 664.
• The required dimensions and
weights are to be taken into account!
• Check the load-bearing capacity of the
proposed wall!
• see A 11 Dimensions Sheet
A 4.1 Room prerequisites
With Group I building materials
Wall thickness:
Concrete 200 mm
Bricks 115 mm
Solid limestone 240 mm
the set of screws supplied must be used.
With Group II building materials
Wall thickness:
Perforated bricks 115 mm
Porous bricks 115 mm
Perforated limestone 240 mm
Light concrete (pumice) 115 mm
Gas concrete 240 mm
Hollow blocks of light concrete 240 mm
injection dowel plugs Mat. No. 0.224.6666
and screw Mat. No. 0.251.0202 with washer
Mat. No. 0.242.4022 must be used
(not included in parts supplied).
