Operation and Service KBL 6800/6900
Replacing tubes
and starters in
inductive units
For units with inductive control, please note:
The starter of the upper tube (#21) in the lateral part is located
behind the decorative light tube on the left hand side (foot area).
Illustr. 5-9 Starter of tube 21
Illustr. 5-10 Left socket for tube 21
Illustr. 5-11 Back of lateral re!ector with starter of tube 21
