36
Operation and Service KBL 6800/6900
6.2 Views
Ø~11.81“
~48.43“
~62.6“
~92.91“
~53.15“
~55.12“
~70.87“
Illustr. 6-1 Front view Illustr. 6-2 Lateral view
Illustr. 6-3 Front view Illustr. 6-4 Lateral view
6.2.1 KBL 6800
6.2.2 KBL 6900
