KBL 6800 - Internal MP3 Player Music Signal

39
Music ampli! er
3220 2885 00
E8: 6 5 ... 2 1
Interface card
3220 3230 60
MP3
megaVoice
3220 3222 95
Music ampli! er
3220 2885 00
E8: 6 5 ... 2 1
I
2
C Audio-
switch
3220 3230 20
MP3
megaVoice
3220 3222 95
MP3 Musik
3220 3222 90
Operation and Service KBL 6800/6900
7.2 megaVoice without music option
Music ampli•er
3220 2885 00
Via an interface card, the MP3-player megaVoice is connected
to the music ampli!er, which leads to the loudspeakers
(connected in parallel, equal-phased).
7.3 Internal music signal MP3-player
MP3-player and megaVoice are connected to the Audio switch
which leads the music signal to the ampli!er and then to the
loudspeakers (connected in parallel, equal-phased).
Audio switch MP3 Music MP3 megaVoice
