Assembly Instructions | megaSun K9S
33
4.13 Disassemble the canopy
4.13.1 LOOSEN THE LOCKING SCREW AND LOCK THE HINGE
4.13.2 PULL OFF PLASTIC PANELS
A
A
A
ISK5 SW13
