9
4.1 Tools and aids
Cutter knife
Allen wrench
SW 6
SW 5
SW 4
Standard Phillips screwdriver
PH2
Screwdriver
3mm
Spanner
SW 17
SW 13
SW 10
Reversible ratchet handle 1/4“ with AF
socket
SW 17
SW 13
Spacer and protective padding e.g. tim-
ber beams, foam strips and blankets.
Adhesive tape (masking tape)
2 (optimal 4) furniture trolleys
technicians required for this maintenance task.
Suction cup
Tape rule or folding rule
Spirit level
Side cutter
TORX wrench
TX4
The disassembly and assembly steps of the tanning
device are described in the following chapters.
The tools and hardware required to correctly and
safely perform these steps are shown at the begin-
ning of each chapter.
Cable ties which have been removed dur-
ing disassembly have to be replaced dur-
ing assembly.
