Copyright 2011 KE2 Therm Solutions, Washington, Missouri 63090
KE2 EvaporatorEfciency
Installation Instructions
thermsolutions
TM
Installation N.1.1 August 2011
Page 10
R 0.210
R 0.105
11.75
9.0
0.5
2.2
Pressure Transducer
0.75
6.75
1.40
2.03
0.67
0.95
5.75
2.03
6.5
female 1/4”
SAE with
depressor
Temperature Sensor
10.0 ft.
.25
1.50
1.50
0.187
Figure 9 - KE2 Evaporator Eciency - Dimensions (front view)
Dimensions - Inches
Depth 2.45”
