KEB COMBICONTROL C5 User Manual

GB - 21
COMBICONTROL
rc.01
seconds
Address 0401h
This parameter displays the seconds in a range of 0...59. Writing on this parameter ad-
justs the seconds.
rc.02
date
Address 0402h
This parameter displays the date in a DD-MM format. Writing on this parameter adjusts
the date.
rc.03
year
Address 0403h
This parameter displays the year in four digits. Writing on this parameter adjusts the year.
rc.04 data valid Address 0404h
The real-time clock is running for approx. 30 days after switching off the supply. After this
it must be adjusted again. If this parameter has the value „false“, the date and/or time is
not correct. The clock must be adjusted.
3.3.4 Process image
pi.00 inputs Address 0500h
Displays the condition of the local inputs.See section in-/output module. Set 0 displays
the rst word, set 1 displays the second.word, etc.
pi.01 outputs Address 0501h
Displays the condition of the local outputs.See section in-/output module. Set 0 displays
the rst word, set 1 displays the second.word, etc.
pi.02 axis indata 1 Address 0502h
Displays the value of the rst process-input data (32 Bit) of the axes. Set 0 is for the data
of axis 1, set 1 for the axis 2, etc.
pi.03 axis outdata 1 Address 0503h
Displays the value of the rst process-output data (32 Bit) of the axes. Set 0 is for the
data of axis 1, set 1 for the axis 2, etc.
pi.04 axis indata 2 Address 0504h
Displays the value of the second process input data (16 Bit) of the axes. Set 0 is for the
data of axis 1, set 1 for the axis 2, etc.
pi.05 axis outdata 2 Address 0505h
Displays the value of the second process-output data (16 Bit) of the axes. Set 0 is for the
data of axis 1, set 1 for the axis 2, etc.
pi.06 axis indata 3 Address 0506h
Displays the value of the third process-input data (16 Bit) of the axes. Set 0 is for the data
of axis 1, set 1 for the axis 2, etc.
