KEB COMBICONTROL C5 - Interface and Standards; Adapter Cable for HSP5 Operator; Comparison of Standards

GB - 10
COMBICONTROL
2.2.5 Adapter cable HSP5 interface operator
Screw terminal:
Color see below
C5 PCC
X1A…H
Signal TXD+ TXD- GND RXD+ RXD- GND EnTXD+ EnTXD-
PIN 1 2 3 4 5 6 7 8
| | | | | | | |
PIN 4 3 9 2 1 9 8 7
Operator
X6E
Signal RXD+ RXD- GND TXD+ TXD- GND EnRxD+ EnRxD-
Color see below
RJ45 connection:
Color see below
C5 PCC
X1A...H
Signal TXD+ TXD- GND RXD+ RXD- GND EnTXD+ EnTXD-
PIN 1 2 3 4 5 6 7 8
| | | | | | | |
PIN 1 2 3 4 5 6 7 8
Operator
RJ45
Signal RXD+ RXD- GND TXD+ TXD- GND EnRxD+ EnRxD-
Color see below
In c a s e o f p r o d u c t I o n o f o w n c o n n e c t I n g c a b l e s p l e a s e p a y a t t e n t I o n t h a t t h e s I g n a l p a I r s (e.g.
txd+ a n d txd -) a r e a s s I g n e d t o t h e c o r r e s p o n d I n g t w I s t e d c a b l e s (e.g. g r e e n a n d g r e e n /
w h I t e ). co n n e c t u n -u s e d s c o r e s a l w a y s t o gnd.
2.2.6 Comparison of the standards
Pair PIN EIA/TIA 568B EIA/TIA 568A DIN 47100 IEC 189.2 USOC
3 1 orange/white green/white green red black
3 2 orange green yellow orange yellow
2 3 green/white orange/white grey black orange
1 4 blue blue brown blue red
1 5 blue/white blue/white white white green
2 6 green orange pink green brown
4 7 brown/white brown/white blue yellow grey
4 8 brown brown red brown blue
