1.5 Technical data
General
Dimensions (HxBxT) 125 x 44 x 144 mm
Weight approx. 260 g
Installation method 35 mm Mounting rail
Grounding via terminal strip or plug-in contact
Protective system (EN 60529) IP20
Operation temperature -10…45 °C (14…113 °F)
Storage temperature -25…70 °C (-13…158 °F)
Climatic category (EN 60721-3-3) 3K3
Environment (IEC 664-1) Pollution degree 2
Control
Operating voltage control (US) 18…30 V DC ±0 %
Power input control 3 W max.
Digital inputs/outputs
Wiring system cage-clamp terminals
Operating voltage inputs/outputs (UM) 18…30 V DC ±0 %
Output current max. 0,7 A per channel, short-circuit proof,
free-wheeling diode integrated
Input voltage/current according to IEC 61131-2 Type 1
Axis interface
Type HSP5/485
Connector RJ-45, 8-pole, screened
Cable Cat5, max. 100 m
Speed 38,4…250 kBaud
Use Connection to KEB F5 inverter/servo, process
data transmission, communication channel
Ethernet interfaces
Type IEEE802.3
10/100BaseTx
2-Port Switch
Connector RJ-45, 8-pole, screened
Speed 10/100 MBaud
autocrossover
