Relay output
Relay output (terminal X1.1...X1.3) is adjusted in the factory as a fault
relay. This parameter can adjust the function of the output onto any
function listed in the table below.
Value Function
0 No function
1 Generally on
2 Fault relay
3 No function
4 Overload alert signal (10s before switch off)
5 * Overtemperature alert signal inverter
6 * Overtemperature alert signal motor (10s before switch off)
7 No function
8 Max. constant current (stall, CP.15) exceeded
9 Max. LA-/LD-Stop (CP.14) exceeded
10 DC-braking active
11 No function
12 Rate of utilization (CP.3) > 100%
13 No function
14 Actual value=set value (CP.2 = Fcon, rcon; not at noP, LS, error, SSF)
15 Accelerate (CP.2 = FAcc, rAcc, LAS)
16 Decelerate (CP.2 = FdEc, rdEc, LdS)
17 Right handed rotation (not at noP, LS error)
18 Left handed rotation (not at noP, LS error)
19 Real direction of rotation = set direction of rotation
20 Real value > frequency level CP.23
21 Set value > freqeuncy level CP.23
22 No function
23 Operating signal (after initialization as long as no error is active)
24 Run signal
25 No function (not available since software version 1.1)
Factory setting: 2
Note: Enter-Parameter
Customer adjustment: _______
This parameter determines the switching point for the relay output
X1.1...X1.3 at CP.22 = "20” or “21”
After the switching of the relay, the frequency can move within a 0.5 Hz
window, without the relay dropping off.
Adjustment range: 0.0...409.58 Hz
Resolution: 0.0125 Hz
Factory setting: 4 Hz
Customer adjustment: _______
Frequency level
Operation of the Unit
* available as of software
version 1.1
