1 ... Front of the housing, direction upwards
2 ... Cut for fan case
Information
The fan case has to be inserted straight into the slot, otherwise the inter-
nal connector would not plug in.
6) Fix the fan case with the screw.
The fan is now replaced.
CP 263/S, CP 263/X Maintenance
© KEBA 2014
Project engineering manual V1.01 37
