Keebox W150NR User Guide

KEEBOX Wireless 11n Router
Fields Description
WAN Interface Type Use the drop-down list to choose between Dynamic IP and Static IP.
Hostname The selection appears when choosing Dynamic IP in WAN Interface Type. This
field is optional, but may be required by some ISPs. The default host name is the
device name of the Router and may be changed.
MAC address The selection appears when choosing Dynamic IP in WAN Interface Type. The
default MAC address is set to the WAN’s physical interface MAC address on the
Router. You can use the Clone MAC button to copy the MAC address of the
Ethernet Card installed by your ISP and replace the WAN MAC address with the
MAC address of the Router. It is not recommended that you change the default
MAC address unless required by your ISP.
My IP address The selection appears when choosing Static IP in WAN Interface Type. Enter
the IP address assigned by your ISP.
My Subnet Mask Enter the subnet mask assigned by your ISP.
Gateway IP Address Enter the Gateway assigned by your ISP.
Login Enter the PPTP login name.
Password Enter the PPTP password.
Service IP address Enter the ISP service IP address.
MTU Maximum Transmission Unit is for optimal performance with some ISPs.
Type Use the drop-down list to select Keep Connection, Automatic Connection or
Manual Connection.
Idle Timeout This is an age-out value, in minutes, before the Router times out.
Click Apply to save the changes.
24

Keebox W150NR Specifications

General

Ethernet LAN	Yes
Cabling technology	10/100Base-T(X)
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3u
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
Modulation	16-QAM, 64-QAM, BPSK, CCK, DBPSK, DQPSK, OFDM, QPSK
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Channels quantity	13 channels
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
WLAN data transfer rate (max)	150 Mbit/s
Input current	1 A
Rack mounting	-
Frequency range	2.4 - 2.4835 GHz
Minimum system requirements	- Internet Explorer 6.0, Firefox, Safari, Chrome
WLAN data transfer rates supported	11, 54, 150 Mbit/s
Ethernet LAN (RJ-45) ports	5
Routing protocols	RIP-1, RIP-2
Supported network protocols	PPPoE, PPTP, L2TP
Antennas quantity	1
Antenna gain level (max)	17 dBi
Security algorithms	128-bit WEP, 64-bit WEP, WPA, WPA2-PSK
Certification	- CE, FCC
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	0 - 95 %
Product color	White
Cables included	LAN (RJ-45)

Weight and Dimensions

Depth	110 mm
Width	150 mm
Height	25 mm
Weight	200 g
