KEEBOX Wireless 11n Router
Port Trigger
Some applications require multiple connections, such as Internet gaming, video conferencing, Internet
telephony and others. These applications have difficulties working through NAT (Network Address
Translation). Special Applications makes some of these applications work with the Router.
Fields Description
Enable Trigger
Port
Tick the check box to enable the function.
Description Enter the description of this rule.
Popular
applications
Use the drop-down list to select an application or click Add to create a new one.
Trigger port This is the port used to trigger the application. It can be either a single port or a range
of ports.
Trigger type Use the drop-down list to select the trigger type as TCP, UDP or Both.
Public port This is the port number on the WAN side that will be used to access the application.
Public type Use the drop-down list to select the pblic type as TCP, UDP or Both.
Schedule Use the drop-down list to choose the appropriate time to enable the MAC filtering
function. Select Always to enable the function all the time. To create a new schedule,
click New Schedule to link to System > Schedule.
Click Add to save the changes and see the rule in the MAC Filtering table. To remove a specific entry,
tick the corresponding check boxes under Select, and click Delete Selected. To remove all entries, click
Delete All. Click Reset to clear all the information that has not been saved.
Click Apply to save the changes.
40
