Keebox W150NR User Guide

KEEBOX Wireless 11n Router
DDNS
The Router supports DDNS (Dynamic Domain Name Service). The Dynamic DNS service allows a
dynamic public IP address to be associated with a static host name in any of the many domains, allowing
access to a specified host from various locations on the Internet. This is enabled to allow remote access
to a host by clicking a hyperlinked URL in the form hostname.dyndns.org, Many ISPs assign public IP
addresses using DHCP, this can make it difficult to locate a specific host on the LAN using standard DNS.
If for example you are running a public web server or VPN server on your LAN, this ensures that the host
can be located from the Internet if the public IP address changes. DDNS requires that an account be
setup with one of the supported DDNS providers.
Fields Description
Dynamic DNS Click the Enable radio button to enable supporting for DDNS.
Server Address Select one of the DDNS registration organizations form those listed in the pull-down
menu.
Host Name Enter the host name of the DDNS server.
Username Enter the username given to you by your DDNS server.
Password Enter the password or key given to you by your DDNS server.
Click Apply to save the changes.
46

Keebox W150NR Specifications

General

Ethernet LAN	Yes
Cabling technology	10/100Base-T(X)
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3u
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
Modulation	16-QAM, 64-QAM, BPSK, CCK, DBPSK, DQPSK, OFDM, QPSK
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Channels quantity	13 channels
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
WLAN data transfer rate (max)	150 Mbit/s
Input current	1 A
Rack mounting	-
Frequency range	2.4 - 2.4835 GHz
Minimum system requirements	- Internet Explorer 6.0, Firefox, Safari, Chrome
WLAN data transfer rates supported	11, 54, 150 Mbit/s
Ethernet LAN (RJ-45) ports	5
Routing protocols	RIP-1, RIP-2
Supported network protocols	PPPoE, PPTP, L2TP
Antennas quantity	1
Antenna gain level (max)	17 dBi
Security algorithms	128-bit WEP, 64-bit WEP, WPA, WPA2-PSK
Certification	- CE, FCC
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	0 - 95 %
Product color	White
Cables included	LAN (RJ-45)

Weight and Dimensions

Depth	110 mm
Width	150 mm
Height	25 mm
Weight	200 g
