Keebox W150NR User Guide

KEEBOX Wireless 11n Router
Idle Timeout This is an age-out value, in minutes, before the Router times out.
Click Apply to save the changes.
Wireless 2.4GHZ
This chapter provides more manual settings about Wireless connection.
Basic
This window allows you to define SSID and the channel for the wireless connection.
Fields Description
Radio Use the radio buttons to enable or disable the wireless function.
Schedule Use the drop-down list to choose the appropriate time to enable the wireless function.
Select Always to enable the function all the time. To create a new schedule, click New
Schedule to link to System > Schedule.
Wireless Mode Use the drop-down list to choose the type of wireless.
SSID Service Set Identifier (SSID) is the name of the wireless network.
Auto channel Click Enable to allow the Router to select the channel with the least amount of
interference. Click Disable to manually select the channel below.
Channel Use the drop-down list to select the channel of wireless network.
WMM Enable Tick the check box to enable Wi-Fi Multimedia to enjoy basic quality of service
features.
Click Apply to save the changes.
26

Keebox W150NR Specifications

General

Ethernet LAN	Yes
Cabling technology	10/100Base-T(X)
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3u
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
Modulation	16-QAM, 64-QAM, BPSK, CCK, DBPSK, DQPSK, OFDM, QPSK
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Channels quantity	13 channels
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
WLAN data transfer rate (max)	150 Mbit/s
Input current	1 A
Rack mounting	-
Frequency range	2.4 - 2.4835 GHz
Minimum system requirements	- Internet Explorer 6.0, Firefox, Safari, Chrome
WLAN data transfer rates supported	11, 54, 150 Mbit/s
Ethernet LAN (RJ-45) ports	5
Routing protocols	RIP-1, RIP-2
Supported network protocols	PPPoE, PPTP, L2TP
Antennas quantity	1
Antenna gain level (max)	17 dBi
Security algorithms	128-bit WEP, 64-bit WEP, WPA, WPA2-PSK
Certification	- CE, FCC
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	0 - 95 %
Product color	White
Cables included	LAN (RJ-45)

Weight and Dimensions

Depth	110 mm
Width	150 mm
Height	25 mm
Weight	200 g
