A Technical Specifications
KR-RM Series(1～3kVA) UPS
User Manual
30
All rights reserved ©Xiamen Kehua Hengsheng Co., Ltd.
A Technical Specifications
Model
Index
KR1000-RM
KR2000-RM
KR3000-RM
Input features
Voltage range(V)
When the voltage range is 176Vac～295Vac, it can connect with more than
75% load; when the voltage range is 154Vac～176Vac, it can connect with
50～75% load; when the voltage range is 120Vac～154Vac, it can connect
with less than 50% load.
Frequency range(Hz)
50/60±10%(50/60 self-adaption)
Phase
Single phase three wire
Battery voltage(V)
36
48
72
Output features
Power capacity(VA/W)
1000/900
2000/1800
3000/2700
Voltage(V)
208/220/230/240±1%(settable)
Frequency(Hz)
50/60±0.1(battery mode)
Wave
Sine-wave
Voltage distortion
THD <3%(linear load)
Power factor
0.9(if the environment temperature is lower than 30℃, it can reach to 1.0,
optional)
Transfer time between
battery mode and mains
0
