Keiser M SERIES Assembly And Operation Manual

M5i | M5 STRIDER ELLIPTICAL
07
Figure 2. Parts List
Qty Description Keiser Part Number
1
Handlebar Assembly 560809
1
1Media Tray (M5i standard, M5 optional equipment) 565063
5
2Handles 560810
2
3
1Top Frame with Computer Display -
2Hanger Pedal Mounts 560906
4
8Socket Button Head Cap Screw (M8X1.25X12 SS) 9515
10
9
8Rubber Bolt Cover 565058
1Hex Head Cap Screw (M8X1.25X80 SS) 9518
11
2Large Washer (FW USS 5/16 ZP) 9344
15
12
18Small Washer (ACFT 5/16 SS) 9369
1Elastic Lock Nut (M8X1.25 SS) 9521
13
1Main Frame -
6
8Hex Head Cap Screws (M8X1.25X10 SS) 9514
14
2Aluminum Caps (pre-assembled with O-rings) 565005
7
8
1Loctite
®
242 Threadlocker 105550
2Socket Head Cap Screw (M8X1.25X14 SS) 9504
16
2Hex Head Cap Screw (M8X1.25X16 ZP) 9511
17
1 2
7 9
5
6
12
10
11
13
14
15
16
17
3
8
4
PARTS LIST
Familiarize yourself with the parts below before you continue to the unpacking and assembly procedures.
Damaged or missing parts? Contact Keiser Customer Support by telephone at 1 559 256 8000,
online 24/7 at keiser.com/support, or by email at service@keiser.com.
