Programming examples

Voltage measurement example

— Table 4 shows a typical command sequence to

measure voltage on channel 1 using auto range.

Temperature measurement example

— Table 5 shows a typical command sequence to

measure temperature on channel 1 using a simulated junction with 0°C reference

temperature and a type J thermocouple.

Settings to optimize performance

Range

To achieve the best accuracy, the Model 2182 should be on the lowest possible

measurement range. In most situations, auto range can be used to automatically select the

best range. Auto range is controlled (enabled/disabled) by the AUTO range key (AUTO

annunciator indicates auto range is enabled).

Table 4

Command sequence for voltage measurement example

Command

Comments

*RST Restore GPIB defaults.

:SENS:FUNC ‘VOLT’ Select voltage measurement function.

:SENS:CHAN 1 Select channel 1.

:SENS:VOLT:CHAN1:RANG:AUTO ON Enable channel 1 auto range.

:READ? Trigger and acquire one voltage reading.

1. Model 2182 must be addressed to talk after sending :READ? to trigger and acquire data.

Table 5

Command sequence for temperature measurement example

Command

Comments

*RST Restore GPIB defaults.

:SENS:FUNC ‘TEMP’ Select temperature measurement function.

:SENS:CHAN 1 Select channel 1 for measurement.

:SENS:TEMP:TRAN TC Select thermocouple sensor.

:SENS:TEMP:RJUN:RSEL SIM Choose simulated junction.

:SENS:TEMP:RJUN:SIM 0 Set simulated junction temperature to 0˚C.

:SENS:TEMP:TC J Select type J thermocouple.

:UNIT:TEMP F Select ˚F temperature units.

:READ? Trigger and acquire one temperature reading.

1. Model 2182 must be addressed to talk after sending :READ? to trigger and acquire data.
