Quick Reference Guide 17
Setting limit values
To enter high and low limit values, press the Limits VALUE key to view the present HI1
limit value. Use the cursor and RANGE keys to display the desired value, then press
ENTER. Repeat the process to set LO1, HI2, and LO2 values.
Enabling limits
Press the Limits ON/OFF key to view the present beeper status, then change as necessary.
Press ENTER to return to the normal display. The HI/IN/LO status is displayed along with
the reading. To disable Limits, press the ON/OFF key.
Remote limits programming
SCPI commands
SCPI commands for basic limit testing are listed in Table 9.
Table 9
Limit testing SCPI commands
Command Description
:CALCulate3:LIMit:STATe <b> Enable/disable Limit 1 test: <b> = ON or OFF.
:CALCulate3:LIMit:LOWer <n> Set lower limit for Limit 1: <n> = limit; -100e6 to 100e6.
:CALCulate3:LIMit:UPPer <n> Set upper limit for Limit 1: <n> = limit; -100e6 to 100e6.
:CALCulate3:LIMit:FAIL? Query Limit 1 test result (0 = pass, 1 = fail).
:CALCulate3:LIMit:CLEar[:IMMediate] Clear Limit 1 fail indication.
:CALCulate3:LIMit:CLEar:AUTO <b> Enable/disable Limit 1 auto clear.
:CALCulate3:LIMit2:STATe <b> Enable/disable Limit 2 test: <b> = ON or OFF.
:CALCulate3:LIMit2:LOWer <n> Set lower limit for Limit 2: <n> = limit; -100e6 to 100e6.
:CALCulate3:LIMit2:UPPer <n> Set upper limit for Limit 2: <n> = limit; -100e6 to 100e6.
:CALCulate3:LIMit2:FAIL? Query Limit 2 test result (0 = pass, 1 = fail).
:CALCulate3:LIMit2:CLEar[:IMMediate] Clear Limit 2 fail indication.
:CALCulate3:LIMit2:CLEar:AUTO <b> Enable/disable Limit 2 auto clear.
