Keithley 3720

In this section:
Front panel operation ............................................................... 3-1
Rear panel summary .............................................................. 3-24
Saved setups ......................................................................... 3-30
Save the present configuration ............................................... 3-33
Using the web interface .......................................................... 3-36
Front panel operation
The Series 3700A includes several models that support different features. The following figures show
the front panels of each of the models. A brief description of the features follows the figures.
Figure 18: Model 3706A with DMM front panel
Figure 19: Model 3706A-S front panel (no DMM)
Section 3
Instrument description
