Series 3700A System Switch/Multimeter Reference Manual
Section 3
:
Instrument description
3700AS-901-01 Rev. D/June 2018
3-
29
Analog backplane connector
Refer to the following figure
for analog backplane con
nector information. See
Connection safe
ty
(on
page
3-
30
) before making
any connections.
Figure
34
: Analog backplane
connector
The tables below contain pin numbe
rs and descriptions for the an
alog backplane connector.
Description
Pin
Description
Pin
Analog backplane 3-
HI
5
DMM-SLO
4
Analog backplane 3-
LO
6
DMM-SHI
3
Analog backplane 4-
HI
7
DMM-
LO
2, 9
Analog backplane 4-
LO
8
DMM-
HI
1
Analog backplane 5-
HI
12
AMP
-
LO
2, 9
Analog backplane 5-
LO
13
AMP
10, 11
Analog backplane 6-
HI
14
Analog backplane 6-
LO
15
87
89
