3-2 Measurements and Sourcing Voltage Model 6485 and 6487 User’s Manual
Measurement overview
Current measurements
The basic current measurement capabilities of the Models 6485 and 6487 are summarized
in Table 3-1. Accuracy for each measurement function and range is listed in
the specifica-
tions (Appendix A).
Table 3-1
Basic Model 6485 and 6487 current measurement capabilities
Function Reading Range Available Ranges
Amps ±10fA to ±21mA 2nA, 20nA, 200nA,
2μA,
20μA, 200μA,
2mA, and 20mA
Model 6487 voltage source
The basic voltage source output capabilities of the Model 6487 are summarized in
Table 3-2. Accuracy specifications are shown in Appendix A.
Table 3-2
Basic Model 6487 voltage source output capabilities
Function Output Range Available Ranges
Source voltage ±200μV to ±505V 10V, 50V, 500V

Keithley 6485 Specifications

General

Model	Keithley 6485
Category	Picoammeter
Input Impedance	>10^14 Ohms
Voltage Burden	<200µV
Accuracy	0.4% of reading
Voltage Source Range	Not Applicable
Voltage Source Resolution	Not Applicable
Voltage Source Accuracy	Not Applicable
Interface	IEEE-488
Power Requirements	100V to 240V AC, 50/60Hz
Dimensions	89 mm high x 214 mm wide x 369 mm deep (3.5 in x 8.4 in x 14.5 in)
