Keithley Series 2600 User Manual

A-47
APPENDIX A
Scripts
Print_Data(l_vgssteps,l_vdssteps, l_vds_data, l_id_data, l_vgs_data)
end--function FET_Comm_Source()
function Print_Data(vgssteps,vdssteps, vds_data,id_data, vgs_data)
--Print Data to output queue
--Local Variables
local l_vgssteps = vgssteps
local l_vdssteps = vdssteps
local l_vgs_iteration = 1 --Iteration variable
local l_vds_iteration = 1 --Iteration variable
local l_vds_data = vds_data
local l_id_data = id_data
local l_vgs_data = vgs_data
for l_vgs_iteration = 1, l_vgssteps do
print(“”)
print(“Gate-source Bias (V)”, l_vgs_data[l_vgs_iteration])
print(“Drain-source Voltage (V)”,”Drain-source Current (A)”)
for l_vds_iteration = 1, l_vdssteps do
print(l_vds_data[l_vgs_iteration][l_vds_iteration], l_id_data[l_vgs_
iteration][l_vds_iteration])
end --for
end --for
end --function Print_Data()
--FET_Comm_Source()

Keithley Series 2600 Specifications

General

Model	Series 2600
Measurement Functions	Voltage, Current, Resistance, Power
Resolution	Up to 6.5 digits
Current Source Range	Up to 10A
Communication Interfaces	GPIB, USB
Applications	Semiconductor testing
Category	Source Measure Unit (SMU)
Channels	Single or Dual Channel (varies by model)
