Series 2600 System SourceMeters Reference Manual Range, Digits, Speed, Rel, and Filters 6-11
Return to Section 6 topics 2600S-901-01 Rev. A / May 2006
3. The present rel value will be displayed.
4. Set the desired rel value.
5. With the desired rel value displayed, press ENTER or the Rotary Knob, and
then use EXIT to back out of the menu structure.
Remote rel programming
Rel commands
Rel commands are summarized in Table 6-5.
Table 6-5
Rel commands
Command
1
Description
To set rel values:
smuX.measure.rel.leveli = relval
smuX.measure.rel.levelp = relval
smuX.measure.rel.levelr = relval
smuX.measure.rel.levelv = relval
To enable/disable rel:
smuX.measure.rel.enablei = smuX.REL_OFF
smuX.measure.rel.enablep = smuX.REL_OFF
smuX.measure.rel.enabler = smuX.REL_OFF
smuX.measure.rel.enablev = smuX.REL_OFF
smuX.measure.rel.enablei = smuX.REL_ON
smuX.measure.rel.enablep = smuX.REL_ON
smuX.measure.rel.enabler = smuX.REL_ON
smuX.measure.rel.enablev = smuX.REL_ON
Set current rel value.
Set power rel value.
Set resistance rel value.
Set voltage rel value.
Disable current rel.
Disable power rel.
Disable resistance rel.
Disable voltage rel.
Enable current rel.
Enable power rel.
Enable resistance rel.
Enable voltage rel.
1. smuX = smua for the Model 2601/2611; smuX = smua (Channel A) or smub (Channel B) for the
Model 2602/2612.
Rel programming example
smua.reset() --Restore Series 2600 defaults.
smua.measure.rel.leveli = 0.1 --Set current rel to 100mA.
smua.measure.rel.enablei =
smua.REL_ON
--Enable current rel.
