Keithley SourceMeter 2602 Reference Manual

Table 1-2
Configuration menus
Menu selection
4
Shortcut
5
Description Reference
CHANNEL-A
SRC
MEAS
LIMIT
SPEED
REL
FILT
OUTPUT
SRC
MEAS
LIMIT
SPEED
REL
FILTER
OUTPUT
Configure channel A:
V-source sense, low range; I-source low range.
V and I -Measure sense, low range; auto zero.
V-source and I-source compliance limits.
Measurement speed (NPLC).
Set relative values.
Control digital filter.
Set off-state, control digital I/O.
Section 4
Section 4
Section 4
Section 6
Section 6
Section 6
Section 3
Section 10
CHANNEL-B
SRC
MEAS
LIMIT
SPEED
REL
FILT
OUTPUT
SRC
MEAS
LIMIT
SPEED
REL
FILTER
OUTPUT
Configure channel B:
V-source sense, low range; I-source low range.
V and I-Measure sense, low range; auto zero.
V-source and I-source compliance limits.
Measurement speed (NPLC).
Set relative values.
Control digital filter.
Set off-state, control digital I/O.
Section 4
Section 4
Section 4
Section 6
Section 6
Section 6
Section 3
Section 10
COMMON
TRIG
STORE
TRIG
STORE
Configure common functions:
Set trigger in, count, interval, and delay.
Set buffer count and destination.
Section 9
Section 7
Series 2600 System SourceMeters Reference Manual Getting Started 1-21
Return to Section 1 topics 2600S-901-01 Rev. A / May 2006
4. Channel B available only on Models 2602/2612.
5. Press CONFIG followed by indicated key to access directly.
