Figure 10-4
Using Model 2611/2612 Interlock
To output stage
10kW
Rear panel
Chassis ground
Coil resistance
145W +/- 10%
-220V supply
+220V supply
INTERLOCK pin
(on DIGITAL I/O connector)
Read by firmware
Pin 24
Closing
Switch
Enables
200V
Operation
+5V
Pin 23
