12-102 Instrument Control Library Series 2600 System SourceMeters Reference Manual
2600S-901-01 Rev. A / May 2006 Return to Section 12 topics
Remarks
• This attribute is used to read or write to the measurement SMU event registers.
• Reading a status register returns a value. The binary equivalent of the returned value
indicates which register bits are set. The least significant bit of the binary number is
bit 0, and the most significant bit is bit 15.
For example, assume value 257 is returned for the enable register. The binary
equivalent is 0000000100000001. This value indicates that bit B0 (VLMT) and bit B8
(BAV) are set.
• The used bits of the measurement SMU event registers are described as follows:
• Bit B0, VLMT – Set bit indicates that the voltage limit was exceeded. This bit will
be updated only when a measurement is taken or
smuX.source.compliance is
invoked.
• Bit B1, ILMT – Set bit indicates that the current limit was exceeded. This bit will be
updated only when a measurement is taken or
smuX.source.compliance is
invoked.
• Bit B7, ROF – Set bit indicates that an overflow reading has been detected.
• Bit B8, BAV – Set bit indicates that there is at least one reading stored in either or
both of the non-volatile reading buffers.
Details See “Measurement Event Registers” in Appendix D.
Example Sets the BAV bit of the measurement SMU A enable register:
status.measurement.instrument.smuX.enable = status.measurement.BAV
