Keithley SourceMeter 2602 Reference Manual

12-118 Instrument Control Library Series 2600 System SourceMeters Reference Manual
2600S-901-01 Rev. A / May 2006 Return to Section 12 topics
status.questionable.calibration.*
status.questionable.calibration.condition
status.questionable.calibration.enable
status.questionable.calibration.event
status.questionable.calibration.ntr
status.questionable.calibration.ptr
* = condition, enable, event, ntr or ptr
Attribute Questionable calibration event register set.
Usage Reads condition, enable, event, NTR and PTR registers:
quesreg = status.questionable.calibration.condition
quesreg = status.questionable.calibration.enable
quesreg = status.questionable.calibration.event
quesreg = status.questionable.calibration.ntr
quesreg = status.questionable.calibration.ptr
Writes to enable, NTR and PTR registers:
status.questionable.calibration.enable = quesreg
status.questionable.calibration.ntr = quesreg
status.questionable.calibration.ptr = quesreg
Set quesreg to one of the following values:
0 Clears all bits.
status.questionable.calibration.SMUA Sets SMUA bit (B1).
status.questionable.calibration.SMUB Sets SMUB (B2).
quesreg can also be set to the decimal weight of the bit to be set. Examples:
To set bit B1 (SMUA), set quesreg to 2 (2
1
).
To set bit B2 (SMUB), set quesreg to 4 (2
2
).
To set both bits, set quesreg to the sum of the decimal weights of both bits. To set
bits B1 and B2, set
quesreg to 6 (2 + 4).
Remarks
• This attribute is used to read or write to the questionable calibration registers.
• Reading a status register returns a value. The binary equivalent of the returned value
indicates which register bits are set. The least significant bit of the binary number is
bit 0, and the most significant bit is bit 15.
For example, assume value 6 is returned for the enable register. The binary
equivalent is 0000000000000110. This value indicates that bit B1(SMUA) and bit B2
(SMUB) are set.
• The used bits of the questionable calibration registers are described as follows:
• Bit B1, SMUA – Set bit indicates the enabled CAL bit for the SMU A questionable
register is set.
• Bit B2, SMUB – Set bit indicates the enabled CAL bit for the SMU B questionable
register is set.
Details See “Questionable Event Registers” in Appendix D.
Example Sets the SMUA bit of the questionable calibration enable register:
status.questionable.calibration.enable =
status.questionable.calibration.SMUA
