2-14 TSP Programming Fundamentals Series 2600 System SourceMeters Reference Manual
2600S-901-01 Rev. A / May 2006 Return to Section 2 topics
Figure 2-5
Test Script Builder (example
Opened script files are displayed in this window
pane as tabs.
To open and display a script file, double-click the file
name in the Project Navigator.
To display another script file that is already open,
click the desired tab.
Project Navigator
Script file
(1 of 4)
Project folder
(1 of 2)
For each project folder:
Click  to hide
script files.
Click + to display
script files.
Script Editor
Programming Interaction
This tab is used to send commands to the SourceMeter. Responses
to commands (from the console or a script) are also displayed in this tab.
This tab lists task markers placed in the script code or added
directly into this tab.
This tab provides help information for ICL functions
and attributes.
This tab provides ESL reference information.
)
To Next Page
