Kelly KLS-D Brushless Motor Controller User’s Manual V 1.5.02
8
(34)CAN-L:Dark Gray
DJ7091Y-2.3-21 Pin Definition
(15) Micro_SW: Throttle switch input. Gray
(3) Throttle: Throttle analog input, 0-5V. Dark Green
(1) Temp: Motor temperature sensor input. Raddle.
(20) RTN: Signal return. Black
(8) Meter: Copy signal of hall sensors. Dark Blue
(4) 5V: 5V supply output, <40mA. Purple
(2) BOOST: Boost function. Brown
DJ7061Y-2.3-21 Pin Definition
(21) RTN:Signal return. Black
(5) 5V: 5V supply output,<40mA.Purple
(18) Hall A: Hall phase A. Yellow
(17) Hall B: Hall phase B. Dark Green
(16) Hall C: Hall phase C. Dark Blue
Notes:
1. All RTN pins are internally connected.
2. Meter function is to copy either of hall sensors.
3. Switch to 12V is active. Open switch is inactive.
Caution:
Do not apply power until you are certain the controller wiring is correct and has been
double checked. Wiring faults will damage the controller.
Ensure that the B- wiring is securely and properly connected before applying power.
The preferred connection of the system contactor or circuit breaker is in series with the B+
line.
All contactors or circuit breakers in the B+ line must have precharge resistors across their
contacts. Lack of even one of these precharge resistors may severely damage the controller
at switch-on.
