Kelvinator KSV70HRG User Manual

5Installation drawing
Installation drawing
Air Conditioner Qty. Qty.
1
Indoor unit
1
7
Battery (AAA 1.5V)
2
2
Outdoor unit
1
8
Drain elbow & seal 1
3
Indoor unit mounting plate
1
9
Flare nuts 2
4
Mounting plate fixing screws, ST3.9x25 5
10
Installation Manual 1
5
Remote controller 1
11
User manual 1
6
Remote controller holder (optional)
1
NOTE: Appearance of outdoor unit and indoor unit may differ from some models. The actual shape shall prevail.
Installation plate fixing screw
ST3.9x25(5)
Remote
control
Before screwing the remote
controller holder to the wall,
make sure that control signals
are properly received by
indoor unit.
2x AAA batteries
In sites with poor drainage, use block bases
for outdoor unit. Adjust its height until the
unit is leveled. Otherwise, water leakage or
pooling of water may occur.
Where there is a danger of the
unit falling, use foot bolts to fix.
Allow two of A, B and
C directions to be free
from obstructions.
Wrapping tape (wrap the
insulation pipe with the tape
from bottom to top)
30cm or more
30cm or more
15cm or more
200cm or more
12cm or more
12cm or more
Air filter
60cm
or more
60cm or more
200cm or more
Air outlet
3
4
5
6
7
A
1
2
B
8 9
C
Additional drain pipe
Fig. 1
Seal
Drain elbow
Flare nuts
