Kelvion TEC1 - FM Dimensions - Vertical; FM Dimensions (A, B)

Searle Air Cooler
1200
MNTG CRS
1150
740
300
50
Vertical discharge with
spigot attachment
option
Air operated damper &
crowl extension (defrost
units)
Heater
removal
1000 Min
1875
Mesh guard fitted
on all coils
740
2“ BSP (M)
Drain conn
1575
MNTG CRS
16mm
MTG hole
150
412
A
B
Power supply input
Rfrig. connections
Heater
removal
2000 Min
2“ BSP (M)
Drain conn
3150
740
1425
MNTG CRS
16mm
MTG hole
150
412
A
B
MNTG CRS
1425
Power supply input
Rfrig. connections
Heater
removal
2000 Min
2“ BSP (M)
Drain conn
4425
740
1425
MNTG CRS
16mm
MTG hole
150
412
A
B
MNTG CRS
1275
Power supply input
Rfrig. connections
MNTG CRS
1425
Heater
removal
2000 Min
2“ BSP (M)
Drain conn
5700
740
1425
MNTG CRS
16mm
MTG hole
150
412
A
B
MNTG CRS
1275
Power supply input
Rfrig. connections
MNTG CRS
1275
MNTG CRS
1425
Model Dim A Dim B
FM20
1016 1969
FM24 1219
2173
FM30 1524
2477
FM36 1829
2782
FM dimensions - Vertical
1080
Opening
40
40
40
40
40
530
opening
