The TIG-section provides these programmatic functions:
• Pre- and postgas timings
• Up- and downslopes
• Tacking automatics
• Switch functions (2T/4T)
• Pulse functions
• Pulse led control
• Ignition spark control and watch
• Contact ignition control and watch
• Power source start and set value
Mastertig-power source´s TIG-section
Controller part
Operation
voltage
section
Spark
generator
Reset-
generator
Start
-indication
24 VAC
+ 16 V
24 VAC
+ 5 V Spark on/off
+ 16 V
Reset
Start
Solenoid
valve
LED
10 kV
Operation panel
22
