Power source Mastertig MLS™ 3000
Connection voltage
3~ 50/60 Hz 400V –15%…+20%
Rated power at max. current
30% ED TIG 8.4 kVA
40% ED MMA 9.4 kVA
Connection cable
HO7RN-F 4G1.5(5m)
Fuse (delayed)
10 A
Duty cycle 40 °C
MMA 10 A/20.5 V...250 A/30.0 V
TIG 5 A/10.0 V...300 A/22.0 V
Max welding voltage
36 V / 250 A
Stick electrodes
Ø 1.5 ... 5.0 mm
Open circuit voltage
80 V
Welding current control
stepless
Efficiency at max. current
86 % (250 A/30.0 V)
Power factor at max. current
0.95 (250 A/30.0 V)
Idle power
approx. 10 W
Degree of protection
IP23S
EMC class
A
Minimum short circuit power S
sc
of supply network*
1.6 MVA
External dimensions (TIG power source + cooling unit)
LxWxH 500 x 180 x 390 (650) mm
Weight
22 kg
Power source Mastertig MLS™ 4000
Connection voltage
3~ 50/60 Hz 400V –15%…+20%
Rated power at max. current
30% ED TIG 13.8 kVA
40% ED MMA 15 kVA
Connection cable
HO7RN-F 4G2.5(5m)
Fuse (delayed)
16 A
Duty cycle 40 °C
TIG 5 A/10.0 V ... 400 A/26.0 V
MMA 10 A/20.5 V ... 350 A/34.0 V
Max welding voltage
45.0 V / 350 A
Stick electrodes
Ø 1.5 ... 6.0 mm
Open circuit voltage
80 V
Welding current control
stepless
Efficiency at max. current
86 % (350 A/34.0 V)
Power factor at max. current
0.95 (350 A/34.0 V)
Idle power
approx. 10 W
Degree of protection
IP23S
EMC class
A
Minimum short circuit power S
sc
of supply network*
2.5 MVA
External dimensions (TIG power source + cooling unit)
LxWxH 500 x 180 x 390 (650) mm
Weight
23 kg
23
Master, MasterTig, MasterCool 10 / © Kemppi Oy / 1112
