MasterTig 235ACDC, 325DC, 335ACDC, 425DC
Operating manual - EN
Button remote channel
control
OFF / ON (Default = OFF)
Wireless remote
Pairing starts automatically when selected New pairing information replaces the old inform-
ation.
Pairing status is shown as the settings value.
TIG settings:
Parameter Value Note
Balance limit min
-99 ... 0, step 1 (Default =-60)
Balance limit max
0 ... +20, step 1 (Default = 0)
Lift TIG current
5 A ... 40 A / Auto, step 1 A (Default = Auto =
10 A)
HF spark force
50 % ... 110 %, step 1 % (Default = 100 %)
Positive ignition current
30 % ... 150 % / Auto, step 1 % (Default =
Auto)
Positive ignition time
0 ms ... 50 ms / Auto, step 10 ms (Default =
Auto)
Negative ignition current
(ACDC): 100 % ... 300 % / Auto, Step 1 %
(Default = Auto)
Ignition current
(DC): 100 % ... 300 % / Auto, step 1 %
(Default = Auto)
Negative ignition time
(ACDC): 0 ms ... 950 ms / Auto, step 10 ms
(Default = Auto)
Ignition time
(DC): 0 ms ... 950 ms / Auto, step 10 ms
(Default = Auto)
Slight upslope
OFF / ON (Default = OFF)
Startup level
5 % ... 40 %, step 1 % (Default = 10 %)
Downslope cut level
5 % ... 40 %, step 1 % (Default = 10 %)
2T downslope cut
OFF / ON (Default = OFF)
Nonlinear downslope
0 % ... 50 %, step 1 % (Default = 0 %)
Current freezing
OFF / ON (Default = OFF)
TIG antifreeze
OFF / ON (Default = OFF)
AC phase swap current
5 A ... 20 A / Auto
MMA settings:
Parameter Value Note
Welding current
Min/Max = Normal welding current limits
Hot start
-10 ... +10, step 1 (Default = 0)
Arc force
-10 ... +10, step 1 (Default = 0)
MMA antifreeze
OFF / ON (Default = OFF)
© Kemppi
47
1920900 / 2052
