MasterTig 235ACDC, 325DC, 335ACDC, 425DC
Operating manual - EN
3.3.7 Settings view
To adjust settings:
1. Go to the Settings view.
2. Turn the control knob (1) to browse through the settings groups and parameters.
3. Select a parameter to be adjusted or changed by pressing the control knob button (1).
4. Adjust or change the setting by turning the control knob (1).
5. Close the parameter setting by pressing the control knob button (1).
Some of the settings are e.g. current mode and welding process specific and are visible or not visible in the settings
menu accordingly.
Common welding settings:
Parameter Value Note
Welding process
TIG / MMA (Default = TIG) Selecting a welding process changes auto-
matically to the last active channel for the selec-
ted process.
Current limit min
TIG: 2 A / MMA: 8 A, step 1 A
*
Current limit max
TIG: power source's nominal value / MMA:
power source's max. MMA current, step 1 A
*
Remote control mode
OFF/ Remote / Torch (Default = OFF) When a remote control or a torch remote control
is selected, the welding current adjustment on
the control panel is disabled.
Remote control min
Min = “Current limit min”, Max = “Current limit
max”
Remote control max
Min = “Current limit min”, Max = “Current limit
max”
© Kemppi
46
1920900 / 2052
