Kemppi MasterTig MLS 2300 ACDC User Manual

Mastertig MLs™ 2300 aDCD / 0743 – 23© keMppi oy
6. TECHNICAL DATA
Power source Mastertig MLS™ 2300 ACDC
Mains voltage 1~230 V –15%…+15%
Rated power
40% ED TIG 230 A 5,7 kVA
60% ED TIG 200 A 4,8 kVA
100% ED TIG 170 A 3,9 kVA
40% ED MMA 180 A 6,0 kVA
60% ED MMA 150 A 4,8 kVA
100% ED MMA 120 A 3,7 kVA
Connection cable/fuse 3 x 2,5 S mm² – 3,3 m / 16 A delayed
Welding current range
TIG 3 A / 10,0 V...230 A / 19,2 V
MMA 10 A / 20,5 V...180 A / 27,2 V
Max welding voltage 32 V / 180 A (MMA)
Electrode sizes to be welded Ø 1,5...4,0 mm
Open circuit voltage, max. 58 V
Welding current adjustment stepless
Efciency at nominal values 82 % (180 A / 27,2 V),
78 % (230 A / 19,2 V)
Power factor
at nominal values
0,99
Open circuit power TIG 6 W
MMA 180 W
External dimensions
length 430 mm
width 180 mm
height 390 mm
(650 mm power source + cooling unit)
Weight 15 kg
Cooling unit (TIG-welding) Mastercool 20
Connection voltage 230 V -15 %...+15 %
Connection capacity 100 % ED 50 W
Cooling power 1,0 kW
Start pressure, max 4,0 bar
Cooling liquid 20 % - 40 % glycol-water
Reservoir volume approx. 3 l
External dimensions
length 500 mm
width 180 mm
height 260 mm
Weight 8 kg
Power source and cooling unit
Operating temperature range -20 ºC .... +40 ºC
Storage temperature range -20 ºC .... +60 ºC
Degree of protection IP 23 C
Recommended generator Smin 8 kVA
The products meet conformity requirements for CE marking.
