Kemppi Minarc Evo 180 Operating Manual

EN
6. TECHNICAL DATA
Minarc Evo 180
Connection voltage
1 ~ 50/60 Hz 230 V ± 15 %
Connection voltage (AU)
1 ~ 50/60 Hz 240 V ± 15 %
Rated power at max. current
30 % ED MMA 170 A / 5.7 kVA
35 % ED TIG 180 A / 4.0 kVA
Supply current
30 % ED I
1max
24 A
100 % ED I
1e
15 A
Supply current (140 AU)
100 % ED I
1e
10.0 A
Connection cable
H07RN-F 3G1.5 (1.5 mm2, 3 m)
Fuse
type C 16 A: 170 A ED 30%
10 A: 140 A ED 28%
Output 40 °C
30 % ED MMA 170 A / 26.8 V
100 % ED MMA 115 A / 24.6 V
35 % ED TIG 180 A / 17.2 V
100 % ED TIG 130 A / 15.2 V
Output 40 °C (140 AU)
28 % ED MMA 140 A / 25.6 V
100 % ED MMA 80 A / 23.2 V
Welding range
MMA 10 A/15 V – 170 A/32 V
TIG 10 A/10 V – 180 A/30 V
Open circuit voltage
average 90 V; VRD 30 V; AU VRD 12 V
No-load power
30 W
Voltage steps
stepless
Power factor at 100 % ED
0.99
Efficiency at 100 % ED
MMA 84 %
Stick electrodes
ø 1.5 – 4.0 mm
External dimensions LxWxH
height with handle 361x139x267 mm
Weight
without connection cable 5.4 kg
with connection cable 5.85 kg
Temperature class
F (155 °C)
EMC class
A
Degree of protection
IP23S
Operating temperature range
–20…+40 °C
Storage temperature range
–40…+60 °C
Standards
IEC 60974-1
IEC 60974-10
IEC 61000-3-12
Minarc Evo 180
14

Kemppi Minarc Evo 180 Specifications

General

Input Voltage	230 V
Protection Class	IP23S
Welding Processes	MMA, TIG
Open Circuit Voltage	85 V
Electrode Sizes	1.5 - 4.0 mm
Input Frequency	50/60 Hz
Power Factor	0.99
Efficiency	82%
