WFX 200, 300, 200 P Fe/Ss, 300 P Fe/Ss, 200-T, 300 P-T, 300-T, 200 AMC, 300 AMC
32
EN
8. TECHNICAL DATA
WFX 200, 200 P Fe,
200 P Ss, 200-T,
200 AMC
300 P Fe, 300 P Ss,
300 P-T
300, 300-T,
300 AMC
Operating voltage
(safety voltage)
50 V DC 50 V DC 50 V DC
Rated power
100 W 250 W 100 W
Output 40 °C
60 % ED 520 A 520 A 520 A
100 % ED 440 A 440 A 440 A
Wire feed speed
1 – 25 m/min 0.5 – 25 m/min 1 – 25 m/min
Wire feed mechanism
4-roll 4-roll, two motors 4-roll
Diameter of feed rolls
32 mm 32 mm 32 mm
Filler wires
ø Fe, Ss 0.6 – 1.6 mm 0.6 – 2.0 mm 0.6 – 1.6 mm
ø Cored wire 0.8 – 2.0 mm 0.8 – 2.4 mm 0.8 – 2.0 mm
ø Al 0.8 – 2.4 mm 0.8 – 2.4 mm 0.8 – 2.4 mm
Wire spool
max. weight 5 kg 20 kg 20 kg
max. ø 200 mm 300 mm 300 mm
Maximum gas pressure
0.5 MPa 0.5 MPa 0.5 MPa
Gun connection
Euro Euro Euro
Operation temperature range
-20 ... +40 °C -20 ... +40 °C -20 ... +40 °C
Storage temperature range
-40 ... +60 °C -40 ... +60 °C -40 ... +60 °C
EMC class
A A A
Degree of protection
IP23S IP23S IP23S
External dimensions
L x W x H 510 x 200 x 310 mm 590 x 240 x 445 mm 625 x 243 x 476 mm
Weight
9.4 kg 13.1 kg 12.5 kg
