Ken DW 412 - Page 41

34-1
6
213
9
DT 16725-1
34-2
blå/blue/blau
M1
U1 V1 W1
W2
V2
U2
3
3 x 380-400V + N, 50/60Hz
VL1
L1 N
Supply Mains connection
L2 L3 PE
C1
24
13
6
5
T1
5
3
1
6
4
2
VL2
C2
24
13
6
5
T2
5
3
1
6
4
2
C3
24
13
6
5
123 456
J13-2 J13-1
12 3
1
0-1
12 3
789
45 6
10 11 12
13 14 15 16 17 18
12 3 12 3
6-12
6-03
11V-AC
2A
34
blå/blue/blau
M1
U1 V1 W1
W2
V2
U2
3
12 3
1
L1
Supply Mains connection
L2 L3 PE
0-1
C1
24
13
6
5
T1
5
3
1
6
4
2
12 3
789
C2
24
13
6
5
T2
5
3
1
6
4
2
45 6
10 11 12
C3
24
13
6
5
13 14 15 16 17 18
3 x 220-230V, 50/60Hz
VL1 VL2
123 456
J13-2
J15
123 456
J14
J13-1
KEN-7600567
41 42 43
43 41 42
nc nc nc
2
6A
12 3 12 3
0-2
TR1
C1 Kontaktor varmelegeme VL1 / Contactor Heating Element VL1 / Schütz, Heizstab VL1 C2 Kontaktor varmelegeme VL2 / Contactor Heating Element VL2 / Schütz, Heizstab VL2 C3 Kontaktor vaskepumpe/ Contactor, wash pump/ Schütz. Umwälzpumpe M1 Vaskepumpe/Wash pump/ Umwälzpumpe T1 Tørkogningssikring vasketank/ Boil- off cut out Washing Tank/Trockenkochsicherung waschen T2 Tørkogningssikring skylletank/ Boil- off cut out Rinsing Tank/ Trockenkochsicherung nachspülung
TR1 Transformer / Transformer / Transformator 230v/11v VL1 Varmelegeme vasketank / Heating Element, Washing / Heizstab, waschen VL2 Varmelegeme skylletank / Heating Element, Rinsing / Heizstab, nachspülung
Tegn. nr.:
Dato / initialer:
Brobyværk, DK 5672 Broby Tlf. 62 63 10 91 Telefax 62 63 16 07
Dato Sign.
Rett.-nr.
Beskrivelse
DW 410/412 Main Circuit 230/400V, 50/60hz
26-10-2009 / SHH
-
