30
Electrical Shock Hazard can occur and result in
serious injury or death. Disconnect appliance from electric power
before cleaning and servicing the warmer drawer.
NOTE: The Warmer Drawer will NOT
operate while in the Self-Clean and
“Oven Lockout” modes
To Remove and Replace Warmer (Warm & Ready™) Drawer
(some models)
To Remove Warmer Drawer:
1.
Turn power OFF before removing the warmer drawer.
2. Open the drawer to the fully opened position.
3. On the right glide you will find a shield attached with a hex-head screw
(See Fig. 1). Use a 1/4” socket and ratchet remove the shield.
4. Locate glide lever on each side of drawer, pull up on the left glide lever and
push down on the right glide lever.
5. Pull the drawer away from the range.
To Replace Warmer Drawer:
1. Replace shield on the right glide of the drawer body.
2. Pull the bearing glides to the front of the chassis glide (See Fig. 2).
3. Align the glide on each side of the drawer with the glide slots on the range.
4. Push the drawer into the range until levers “click” (approximately 2”). Pull
the drawer open again to seat bearing glides into position. If you do not
hear the levers “click” or the bearing glides do not feel seated
remove the drawer and repeat steps 2-4. This will minimize possible
damage to the bearing glides.
Warmer (Warm & Ready™) Drawer Indicator Light (some
models)
The indicator light is located above the Warmer Drawer thermostat control. It
turns on when the control is set, and stays on until the control is turned OFF.
The warmer drawer is inoperable during the Self-Clean cycle. The indicator light
will not come on during the Self-Clean cycle.
Fig. 1
Fig. 2
Setting Warmer Drawer Controls
• Warmer Drawer Indicator Light
• Removing & Replacing Warmer Drawer
