Part #
Qty
Notes
10039
2 ea
10061
2 ea
10086
1 ea
10087
2 ea
10176
2 ea
10085
Bucket C4
10604
Bucket C4-A
1 ea
NOTE: Specify Color
Bucket Assembly C4 / C4-A
Bolt, 1/4-20 x 3/4 Phil SS
Washer, Flat 1/4 SS
Description
Handle, Bucket Bail
Bushing, Flanged-Bucket
Washer, Lock 1/4
37
37
39
Table of Contents
Table of Contents
1
Introduction
2
Before Operating the Machine
2
Important Safety Instructions
2
Grounding Instructions
3
Carpet Cleaning Instructions
4
Upholstery Cleaning
5
Machine Operation and Troubleshooting
6
Kent Investment Corporation Limited Warranty
6
Trouble Shooting Guide
7
Electrical System
7
Vacuum System
8
Pump System
10
Brush System
11
Repair Manual
13
Removing the Vacuum and Brush Assemblies
13
Replacing the Vacuum/Brush Motor
13
Replacing the Pump Motor (18006)
14
Removing the Brush Assembly (18210)
14
Rebuilding the Brush Assembly (18210)
14
Replacing the Front Nozzle Clip (10031)
14
Replacing the Rear Nozzle Clip (10002)
15
Replacing the Trigger Switch (18207)
15
Replacing the Rocker Switch (10108) & Rocker Switch Cap (10114), or Rocker Switch Assembly (10308)
15
Parts Diagram
16
Brush Assembly C4/C4-A
18
Solution Tank C4
20
Solution Tank C4-A
22
Vacuum Assembly C4
24
Vacuum Assembly C4-A
26
Pump Assembly C4
28
Pump Assembly C4-A
30
Handle Assembly C4/C4-A
35
Bucket Assembly C4/C4-A
38
Lid Assembly C4
40
Lid Assembly C4-A
42
Hand Tool Kit C4/C4-A
44
Final Assembly C4
49
Final Assembly C4-A
50
