KENT C-4 User Manual
5
of 1
of 1 rating
53 pages
Give review
Manual
Specs
To Next Page
To Next Page
To Previous Page
To Previous Page
Loading...
Part #
Qty
Notes
1 ea
10601
1 ea
10377
2 ea
10080
1 ea
10382
2 ea
10609
1 ea
10174
6 ea
10150
6 ea
10275
6 ea
10232
1 ea
Lid Assembly
Lid, Gray (NFS)
Lid Assembly C4-A
Description
7LIDA
Gasket Lid/Duct 1/4 C4-A
Tube, Sight
Washer, Flat #10 SS
Washer, Lock #10 SS
Bolt, 10-24 x 1/2 Phil SS
Cuff, Hose-Lid
Decal, Instruction- Lid
Lid, Plate w/Filter Screen
41
41
43
Table of Contents
Table of Contents
1
Introduction
2
Before Operating the Machine
2
Important Safety Instructions
2
Grounding Instructions
3
Carpet Cleaning Instructions
4
Upholstery Cleaning
5
Machine Operation and Troubleshooting
6
Kent Investment Corporation Limited Warranty
6
Trouble Shooting Guide
7
Electrical System
7
Vacuum System
8
Pump System
10
Brush System
11
Repair Manual
13
Removing the Vacuum and Brush Assemblies
13
Replacing the Vacuum/Brush Motor
13
Replacing the Pump Motor (18006)
14
Removing the Brush Assembly (18210)
14
Rebuilding the Brush Assembly (18210)
14
Replacing the Front Nozzle Clip (10031)
14
Replacing the Rear Nozzle Clip (10002)
15
Replacing the Trigger Switch (18207)
15
Replacing the Rocker Switch (10108) & Rocker Switch Cap (10114), or Rocker Switch Assembly (10308)
15
Parts Diagram
16
Brush Assembly C4/C4-A
18
Solution Tank C4
20
Solution Tank C4-A
22
Vacuum Assembly C4
24
Vacuum Assembly C4-A
26
Pump Assembly C4
28
Pump Assembly C4-A
30
Handle Assembly C4/C4-A
35
Bucket Assembly C4/C4-A
38
Lid Assembly C4
40
Lid Assembly C4-A
42
Hand Tool Kit C4/C4-A
44
Final Assembly C4
49
Final Assembly C4-A
50
Other manuals for KENT C-4
Owner's Manual
6 pages
5
Based on 1 rating
Ask a question
Give review
Questions and Answers:
Need help?
Do you have a question about the KENT C-4 and is the answer not in the manual?
Ask a question
KENT C-4 Specifications
General
Brand
KENT
Model
C-4
Category
Floor Machine
Language
English
