Kentec Electronics Sigma A-CP - Page 55

Code Function Description
53
Set Z3, Coincidence
54
Set Z4, Coincidence
55
Set Z5, Coincidence
56
Set Z6, Coincidence
57
Set Z7, Coincidence
58
Set Z8, Coincidence
61
Set Z1, Configure I.S. Barrier These functions are not UL recognized.
Set this function to configure the Zone I.S. Barrier.
I.S. (Intrinsically Safe) Barriers are used in Europe.
I.S. Barriers separate fire control panels from devices
such as detectors and Pull Stations that are located in
hazardous areas.
62
Set Z2, Configure I.S. Barrier
63
Set Z3, Configure I.S. Barrier
64
Set Z4, Configure I.S. Barrier
65
Set Z5, Configure I.S. Barrier
66
Set Z6, Configure I.S. Barrier
67
Set Z7, Configure I.S. Barrier
68
Set Z8, Configure I.S. Barrier
71
Set Z1, Short Circuit Triggers Alarm The default condition of this function reports
short-circuits as activations under Class A, Style D or
Class B, Style B.
Setting this function changes from reporting
short-circuits as activations to reporting short-circuits
as trouble conditions under Class A, Style E or Class B,
Style C.
Class A circuits are available on zone 1 terminals,
Z1 and Z1 RET only.
72
Set Z2, Short Circuit Triggers Alarm
73
Set Z3, Short Circuit Triggers Alarm
74
Set Z4, Short Circuit Triggers Alarm
75
Set Z5, Short Circuit Triggers Alarm
76
Set Z6, Short Circuit Triggers Alarm
