Relay Ratings
Terminal Ratings
TRBL (NC), (C), (NO)
Power Factor: 1.0
30 VDC @ 1 A maximum, volt free change over contact
Relay Contact: Form C (SPDT)
SUPV. (NC), (C), (NO)
FIRE (NC), (C), (NO)
AUX 24V
Terminal Rating
AUX 24V (+ / -)
15 - 28 VDC, special application, 500 mA maximum
ALM RES
ALM RES inputs are unused on the Sigma A-CP Fire Control Panel:
Terminal Description
SIL
No Connection (NC)
ALM
NC
TRBL
NC
RES
NC
Dialer Board
Condition Rating
Standby Current
20 mA
Alarm Current
60 mA
