Loads Standby Current Alarm Current
AUX 24 V
105 mA (7 AH batteries with
Dialer)
125 mA (7 AH batteries
without Dialer)
280 mA (12 AH batteries
with Dialer)
300 mA (12 AH batteries
without Dialer)
500 mA
Total Maximum Current
225 mA (7 AH Batteries)
400 mA (12 AH Batteries)
5.18 A
Total Standby Current
Total standby-current of the 7 AH standby-batteries must draw less than 225 mA to maintain
continuous standby operation for twenty-four hours followed by five minutes of alarm.
Total standby-current of the 12 AH standby-batteries must draw less than 400 mA to maintain
continuous standby operation for twenty-four hours followed by five minutes of alarm.
Current loading calculations do not include the combined IDC currents of the Sigma A-CP Fire Control
Panel. These combined IDC currents are negligible in comparison to fire control panel, ancillary device
and NAC currents of the Sigma A-CP Fire Control Panel and are therefore excluded from the current
loading calculation.
Field Wiring
The following specifications identify the range of acceptable wire gages for field wiring, battery and
power connections:
Terminals Wire Range
AUX 24V
14 – 22 AWG
ALM RES
No Connection (NC)
NAC 1
14 – 22 AWG
NAC 2
14 – 22 AWG
